Engine / Drive Train Specifications
Engine: 249.9cc, 4-stroke
Cylinder Arrangement: Single cylinder
Max Horsepower: 18.78HP/7500RPM
Max Torque: 13.28ft-lb/5500RPM
Bore × Stroke: 72mm x 61.5mm
Compression Ratio: 9.2:1
Cooling System: Air cooled
Transmission: 5-Speed, Manual
Start System: Electric and Kick Start
Ignition: CDI
Final Drive: Chain drive
Max Speed: 62.14MPH
Battery: 12V6Ah
Frame / Body / Suspension / Brakes
Front Suspension: Dual inverted hydraulic forks and shock absorbers.
Rear Suspension: Swing arm with central adjustable air bag shock absorber.
Front Brake: Hydraulic disc brake.
Rear Brake: Hydraulic disc brake
Front Tires: 80/100-21
Rear Tires: 110/100-18
Capacities / Dimensions
Max Load: 242.55lbs
Gross Weight: 288.86lbs
Net Weight: 280.04lbs
Overall Length: 85.04inches
Overall Width: 36.22inches
Overall Height: 50inches
Carton Dimensions (L × W × H): 69.69×18.11×33.86inches
Seat Height: 38.19inches
Wheelbase: 57.88inches
Ground Clearance: 11.02inches
Gas Tank Capacity: 1.85gal
Fuel Consumption: 65.34mpg
